Alloy Steel Sheets, ASTM A387 Alloy Sheet, Alloy Steel Plates, Alloy Steel Circle, Alloy Steel Coils, ASME SA 387 Alloy Steel Plates, Alloy Steel Hot Rolled Plates Supplier in Mumbai, India.

MSI Fittings is one of the well-known traders and suppliers of Alloy Steel Sheets Plates Coils, which is used by fabricators who serve the oil, gas, and petrochemical industry. The prices that we offer Alloy Steel Plates is the least one can expect and the quality aspect of it is simply exquisite which speaks volumes of the total dimensional accuracy of the product. Alloy Steel Coils are often used in Transformers, Heat Exchangers, Oil Refineries, Brine Heaters, Space Research, Steel industry, Engineering projects, General Piping Industry, etc. The offered Alloy Steel Slatting Coils are manufactured from the finest quality material leading techniques in accordance with the set norms of the industry.

Alloy Steel Cold Rolled Plates, ASTM A387 Alloy Steel Shim Sheets, Alloy Steel Shim Sheets, ASTM A387 Alloy Steel Coils, Alloy Steel Foils Dealer in India.

Alloy Steel Perforated Coils are heavily demanded throughout the market, and known for properties like durability, excellent performance, and ease of maintenance. We are a prominent manufacturer, exporter, and stockiest of Alloy Steel Plates to our respected clients, which are extensively used all over the place for varied purposes. We offer various types of Alloy Steel Coils to our industrial customers, all with a minimum of 99.9 % purity. Alloy Steel Slatting Coils has some great features to offer such as Long life, Corrosion resistance, Permanence in nature, and more. We at MSI Fittings Believe in Offering Prime / Genuine Materials Accompanied with Prompt Personalized Services.

Specification :

Standard	:	ASTM / ASME A/SA 387
Range	:	5 mm To 200 mm thick in 1000 mm TO 2500 mm width & 2500 mm to 12500 mm Length
Grade	:	F 5, F 9, F 11, F 12, F 22, F 91
HSS in Grade	:	M2, M3, M35, M42 Etc.
Form	:	Foils, Shim Sheet, Rolls, Perforated Sheet, Chequered Plate.
Finish	:	2B, 2D, HR,CR, BA NO(8), SATIN (Met with Plastic Coated), Hot rolled plate (HR) Cold rolled sheet (CR)
Specialize	:	Shim Sheet, Perforated Sheet, B. Q. Profile.
Other Services	:	Heat Treatment, Anneling, Pickling, Polish, Electroplating, Anodising, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc.

Technical Specifications of Alloy Steel Plates:

Specification	Chemical Max									Mechanical MPA, min
	C Max	Min Max	Si Max	S Max	P Max	Cr Max	Mo Max	Ni Max	Cu Max	Tensile	Yield	% EL		Bend
												50     GL	50 GL
ASTM A 387
Gr 11 - CI 2	0.17	0.40 0.65	0.50 0.80	0.04	0.035	1.0 1.50	0.45 0.65	---	---	515 690	310	22	18	---
Gr 12 - Cl 2	0.17	0.40 0.65	0.15 0.40	0.04	0.035	0.80 1.15	0.45 0.60	---	---	450 585	275	22	19	---
EN-19	0.35 0.45%	0.50 0.80%	0.10 0.35%	---	0.20 0.40%	0.90 1.50%	--- 0.05	---	---	--- ---	---	---	---	---
Gr 5 - Cl 2	0.15	0.30 0.60	0.50	0.035	0.035	4.0 6.0	0.45 0.65	---	---	515 690	310	18	---	---
Gr 22 - Cl 2	0.15	0.30 0.60	0.50	0.035	0.035	2.0 2.5	0.90 1.10	---	---	515 690	310	18	---	---
ASTM A 204 Gr-B	0.20	0.90	0.15 0.40	0.04	0.035	---	0.45 0.60	---	---	485 620	275	21	17	2T
16 Mo3	0.12 0.20	0.40 0.90	0.35	0.025	0.030	0.30	0.25 0.35	0.30	---	440 590	275	24	---	Impact : +20C / 3

Alloy Steel Plates ASTM A387 Chemical Composition:

	C	Mn	P	S	SI	Cr	Mo
Grade 5	0.15 max	0.3 – 0.6	0.035	0.03	0.5 max	4.00 – 6.00	0.45 – 0.65
Grade 9	0.15 max	0.30 – 0.6	0.03	0.03	1.0 max	8.0 – 10.0	0.9 – 1.1
Grade 11	0.05 – 0.17	0.4 – 0.65	0.035	0.035	0.5 – 0.80	1.0 – 1.5	0.45 – 0.65
Grade 12	0.05 – 0.17	0.4 – 0.65	0.035	0.035	0.15 – 0.4	0.8 – 1.15	0.45 – 0.6
Grade 22	0.05 – 0.15	0.3 – 0.6	0.035	0.035	0.5 max	2.0 – 2.5	0.9 – 1.1

Alloy Steel Plates ASTM A387 Mechanical Properties:

		Tensile Strength (ksi)	Tensile Strength (MPa)	Yield Strength (ksi)	Yield Strength (MPa)	Elongation in 2 inches (%)
A 387 Grade 5	Class 1	60-85	415-585	30	205	18
	Class 2	75-100	515-690	45	310	18
A 387 Grade 9	Class 1	60-85	415-585	30	205	18
	Class 2	75-100	515-690	45	310	18
A 387 Grade 11	Class 1	60-85	415-585	35	240	22
	Class 2	70-90	485-620	45	310	22
A 387 Grade 12	Class 1	50-80	380-550	33	230	22
	Class 2	65-85	450-585	40	275	22
A 387 Grade 22	Class 1	60-85	415-585	30	205	18
	Class 2	75-100	515-690	45	310	18

Comparable Alloy Steel Plate Specifications, Pipe Specifications and Forging Specifications:

Plate Grade	Forging/Flange Grade A182	Pipes Grade ASTM A335
BSEN10028-2 16M03	F1	P1
ASTM A387-12-2	F12-2	P12
ASTM A387-11-2	F11-2	P11
ASTM A387-22-2	F22	P22
ASTM A387-5-2	F5	P5
ASTM A387-91-2	F9	P91

Types of Alloy Steel Plates, Sheets & Coils :

Types of Alloy Steel Sheets, Plates & Coils

Other Grades of Alloy Steel Sheet/Plate/Coil

Alloy Steel Sheets, Plate & Coils Test Certificates

We at MSI Fittings provide Manufacturer TC (Test Certificate) in accordance to EN 10204/3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report. We also provide Standard certificates like EN 10204 3.1 and additional requirement like. NACE MR 01075. FERRIT CONTENT as per norms if requested by clients.

• EN 10204/3.1B,
• Raw Materials Certificate
• 100% Radiography Test Report
• Third Party Inspection Report, etc

ASTM A387, ASME SA387 Alloy Steel Sheets, Plate & Coils Value Added Services

Material Testing:
We at MSI Fittings ensure that all our materials go through strict quality tests before dispatching them to our clients.

• Mechanical Testing Such as Tensile of Area
• Hardness Test
• Chemical Analysis – Spectro Analysis
• Positive Material Identification – PMI Testing
• Flattening Test
• Micro and MacroTest
• Pitting Resistance Test
• Flaring Test
• Intergranular Corrosion (IGC) Test

Documentation

• Commercial Invoice which includes HS Code
• Packing List including net weight and gross weight, number of boxes, Marks and Numbers
• Certificate of Origin legalized/attested by Chamber of Commerce or Embassy
• Fumigation Certificates
• Raw Material Test Reports
• Material Traceability Records
• Quality Assurance Plan (QAP)
• Heat Treatment Charts
• Test Certificates certifying NACE MR0103, NACE MR0175
• Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2
• Guarantee Letter
• NABL approved Laboratory Test Reports
• Welding Procedure Specification/Procedure Qualification Record, WPS/PQR
• Form A for the purposes of the Generalized System of Preferences (GSP)

Alloy Steel Sheets, Plate & Coils Packaging

We do care about the quality of our products even some little details are paid attention to. Each order is packaged according to the customer’s standards including preparation for export such as wooden case, pallet, or according to customer’s requirement, All shipping documentation is provided for Alloy Steel Sheet, Plate and Coil delivery from mill to customer. Every assignment begins with a visit of our experienced sales representative who assesses the volume/weight of the belongings and briefs the client about the nature of packing required as well as various documentation formalities when moving from India.
